UltiMaker S5 vs WASP 2040 Pro
What S5 does better (3) and where 2040 Pro wins (1) — every spec side by side.
Dimensions
Size comparison
S52040 Pro
| S5 | 2040 Pro | Difference | |
|---|---|---|---|
| Height | 585 mm | 870 mm | −285 mm |
| Width | 495 mm | 490 mm | +5 mm |
| Depth | 780 mm | 440 mm | +340 mm |
| Weight | 20.6 kg | 25 kg | −4.4 kg |
Drawn to the same scale from the official dimensions (front and side).
Why is S5 better than 2040 Pro?
- Finest layer height0.02 mm vs 0.05 mm2.5×
- Number of supported materials10 vs 42.5×
- Weight20.6 kg vs 25 kg+21%
Why is 2040 Pro better than S5?
- Max nozzle temperature280 °C vs 350 °C+25%
Specifications
Side by side
| General | ||
| Technology | FDM / FFF (filament) | FDM / FFF (filament) |
| Motion system | — | Delta |
| Build volume | ||
| Build width (X) | 330 mm | — |
| Build depth (Y) | 300 mm | — |
| Build height (Z) | 240 mm | — |
| Build volume | 23.8 L | — |
| Speed | ||
| Max print speed | — | 500 mm/s |
| Print quality | ||
| Finest layer height | 0.02 mm | 0.05 mm |
| Thickest layer height | 0.6 mm | 0.4 mm |
| Extruder & hotend | ||
| Max nozzle temperature | 280 °C | 350 °C |
| Default nozzle | 0.4 mm | 0.4 mm |
| Supported nozzle sizes (mm) | 0.25, 0.4, 0.6, 0.8 | — |
| Nozzle material | — | hardened steel |
| Toolheads | 1 | — |
| Nozzles | 1 | — |
| Filament diameter | 2.85 mm | 1.75 mm |
| Supported materials | Optimized for PLA, Tough PLA, ABS, Nylon, CPE, CPE+, PC, PP, TPU 95A, PVA | PLA, PETG, ABS, PA carbon |
| Number of supported materials | 10 | 4 |
| Engineering materials (PA, PC, CF) | Yes | Yes |
| Print bed | ||
| Heated bed | Yes | — |
| Max bed temperature | 140 °C | — |
| Connectivity & control | ||
| Connectivity | Wi-Fi, Ethernet, USB | SD card |
| Wi-Fi | Yes | — |
| Ethernet | Yes | — |
| USB | Yes | — |
| SD card | — | Yes |
| Screen size | 4.7″ | — |
| Touchscreen | Yes | — |
| Size & power | ||
| Width | 495 mm | 490 mm |
| Depth | 780 mm | 440 mm |
| Height | 585 mm | 870 mm |
| Weight | 20.6 kg | 25 kg |
| Rated power | 500 W | 600 W |
