- Pro2 Plus vs Pro3 Plus
Raise3D Pro2 Plus vs Raise3D Pro3 Plus
What Pro2 Plus does better (3) and where Pro3 Plus wins (3) — every spec side by side.
Dimensions
Size comparison
Pro2 PlusPro3 Plus
| Pro2 Plus | Pro3 Plus | Difference | |
|---|---|---|---|
| Height | 1,105 mm | 1,105 mm | = |
| Width | 620 mm | 620 mm | = |
| Depth | 590 mm | 626 mm | −36 mm |
| Weight | 59.3 kg | 66.6 kg | −7.3 kg |
Drawn to the same scale from the official dimensions (front and side).
Why is Pro2 Plus better than Pro3 Plus?
- Build volume56.3 L vs 54.5 L+3%
- Noise level50 dB vs 55 dB+10%
- Weight59.3 kg vs 66.6 kg+12%
Why is Pro3 Plus better than Pro2 Plus?
- Engineering materials (PA, PC, CF)No · Pro2 Plus: Yes
- Number of supported materials5 vs 132.6×
- Max bed temperature110 °C vs 120 °C+9%
Specifications
Side by side
| General | ||
| Technology | FDM / FFF (filament) | FDM / FFF (filament) |
| Build volume | ||
| Build width (X) | 305 mm | 300 mm |
| Build depth (Y) | 305 mm | 300 mm |
| Build height (Z) | 605 mm | 605 mm |
| Build volume | 56.3 L | 54.5 L |
| Speed | ||
| Max print speed | 150 mm/s | 150 mm/s |
| Print quality | ||
| Finest layer height | 0.01 mm | 0.01 mm |
| Automatic bed levelling | — | Yes |
| Extruder & hotend | ||
| Max nozzle temperature | 300 °C | 300 °C |
| Default nozzle | 0.4 mm | 0.4 mm |
| Nozzles | 2 | 2 |
| Filament diameter | 1.75 mm | 1.75 mm |
| Supported materials | PLA, ABS, HIPS, TPU, PETG | PLA, ABS, HIPS, PC, TPU, TPE, PETG, ASA, PP, PVA, Nylon, Metal Fill, Wood Fill |
| Number of supported materials | 5 | 13 |
| Engineering materials (PA, PC, CF) | No | Yes |
| Print bed | ||
| Heated bed | Yes | Yes |
| Max bed temperature | 110 °C | 120 °C |
| Connectivity & control | ||
| Connectivity | Wi-Fi, Ethernet, USB | Wi-Fi, Ethernet, USB |
| Wi-Fi | Yes | Yes |
| Ethernet | Yes | Yes |
| USB | Yes | Yes |
| SD card | No | — |
| Bluetooth | No | — |
| Features | ||
| Built-in camera | Yes | Yes |
| Filament runout sensor | — | Yes |
| Power-loss recovery | Yes | Yes |
| Size & power | ||
| Width | 620 mm | 620 mm |
| Depth | 590 mm | 626 mm |
| Height | 1,105 mm | 1,105 mm |
| Weight | 59.3 kg | 66.6 kg |
| Rated power | 600 W | 600 W |
| Noise level | 50 dB | 55 dB |
