- LUGO G3 vs E2
LUGOLABS LUGO G3 vs Raise3D E2
What LUGO G3 does better (2) and where E2 wins (5) — every spec side by side.
Dimensions
Size comparison
LUGO G3E2
| LUGO G3 | E2 | Difference | |
|---|---|---|---|
| Height | 532 mm | 465 mm | +67 mm |
| Width | 457 mm | 607 mm | −150 mm |
| Depth | 370 mm | 596 mm | −226 mm |
Drawn to the same scale from the official dimensions (front and side).
Why is LUGO G3 better than E2?
- Max print speed200 mm/s vs 150 mm/s+33%
- Max bed temperature130 °C vs 110 °C+18%
Why is E2 better than LUGO G3?
- Build volume5.6 L vs 19 L3.4×
- Max nozzle temperature285 °C vs 300 °C+5%
- Build height (Z)180 mm vs 240 mm+33%
- Build width (X)190 mm vs 330 mm+74%
- Build depth (Y)165 mm vs 240 mm+45%
Specifications
Side by side
| General | ||
| Technology | FDM / FFF (filament) | FDM / FFF (filament) |
| Build volume | ||
| Build width (X) | 190 mm | 330 mm |
| Build depth (Y) | 165 mm | 240 mm |
| Build height (Z) | 180 mm | 240 mm |
| Build volume | 5.6 L | 19 L |
| Speed | ||
| Max print speed | 200 mm/s | 150 mm/s |
| Print quality | ||
| Finest layer height | — | 0.02 mm |
| Automatic bed levelling | — | Yes |
| Extruder & hotend | ||
| Max nozzle temperature | 285 °C | 300 °C |
| Default nozzle | 0.4 mm | 0.4 mm |
| Nozzles | 2 | 2 |
| Filament diameter | 1.75 mm | 1.75 mm |
| Supported materials | — | ABS, PLA, HIPS, PVA |
| Number of supported materials | — | 4 |
| Engineering materials (PA, PC, CF) | — | No |
| Print bed | ||
| Heated bed | Yes | Yes |
| Max bed temperature | 130 °C | 110 °C |
| Enclosure | ||
| Enclosed build chamber | — | Yes |
| Connectivity & control | ||
| Connectivity | — | Wi-Fi, Ethernet, USB |
| Wi-Fi | — | Yes |
| Ethernet | — | Yes |
| USB | — | Yes |
| SD card | — | No |
| Bluetooth | — | No |
| Touchscreen | Yes | Yes |
| Features | ||
| Built-in camera | — | Yes |
| Power-loss recovery | — | Yes |
| Size & power | ||
| Width | 457 mm | 607 mm |
| Depth | 370 mm | 596 mm |
| Height | 532 mm | 465 mm |
| Weight | 15 kg | — |
| Rated power | — | 350 W |
| Noise level | — | 50 dB |
