Flashforge Creator 5 vs Snapmaker U1
What Creator 5 does better (4) and where U1 wins (7) — every spec side by side.
Dimensions
Size comparison
Creator 5U1
| Creator 5 | U1 | Difference | |
|---|---|---|---|
| Height | 443 mm | 730 mm | −287 mm |
| Width | 520 mm | 584 mm | −64 mm |
| Depth | 710 mm | 499 mm | +211 mm |
| Weight | 14 kg | 18.2 kg | −4.2 kg |
Drawn to the same scale from the official dimensions (front and side).
Why is Creator 5 better than U1?
- Max nozzle temperature320 °C vs 300 °C+7%
- Max bed temperature120 °C vs 100 °C+20%
- Weight14 kg vs 18.2 kg+30%
- Screen size4″ vs 3.5″+14%
Why is U1 better than Creator 5?
- Max print speed300 mm/s vs 500 mm/s+67%
- Build volume16.8 L vs 19.7 L+17%
- EthernetNo · Creator 5: Yes
- TouchscreenNo · Creator 5: Yes
- Build height (Z)256 mm vs 270 mm+5%
- Build width (X)256 mm vs 270 mm+5%
- Build depth (Y)256 mm vs 270 mm+5%
Specifications
Side by side
| General | ||
| Technology | FDM / FFF (filament) | FDM / FFF (filament) |
| Motion system | CoreXY / XY-head | CoreXY / XY-head |
| Delivered as | Fully assembled | Fully assembled |
| All-metal frame | — | Yes |
| Klipper firmware | — | Yes |
| Build volume | ||
| Build width (X) | 256 mm | 270 mm |
| Build depth (Y) | 256 mm | 270 mm |
| Build height (Z) | 256 mm | 270 mm |
| Build volume | 16.8 L | 19.7 L |
| Speed | ||
| Max print speed | 300 mm/s | 500 mm/s |
| Max acceleration | — | 20,000 mm/s² |
| Max volumetric flow | — | 32 mm³/s |
| Print quality | ||
| Finest layer height | — | 0.05 mm |
| Thickest layer height | — | 0.3 mm |
| Vibration compensation (input shaping) | — | Yes |
| Automatic bed levelling | Yes | Yes |
| Extruder & hotend | ||
| Max nozzle temperature | 320 °C | 300 °C |
| Direct-drive extruder | — | Yes |
| Default nozzle | 0.4 mm | 0.4 mm |
| Nozzle material | — | stainless steel |
| Swappable nozzle / hotend | — | Yes |
| Toolheads | 4 | 4 |
| Nozzles | 4 | 4 |
| Filament diameter | 1.75 mm | 1.75 mm |
| Supported materials | BVOH, PETG, PETG-CF, PLA, PLA-CF, PVA, SILK, TPU-64D, TPU-90A, TPU-95A | ABS, ASA, PA, PA-CF, PA-GF, PC, PETG, PLA, PVA, TPU |
| Number of supported materials | 10 | 10 |
| Engineering materials (PA, PC, CF) | Yes | Yes |
| Multi-colour | ||
| Multi-colour printing | Yes | Yes |
| Max colours / materials | 4 | 4 |
| Multi-colour system | toolchanger | toolchanger |
| Print bed | ||
| Heated bed | Yes | Yes |
| Max bed temperature | 120 °C | 100 °C |
| Enclosure | ||
| Enclosed build chamber | — | Yes |
| Actively heated chamber | — | No |
| Chamber light | Yes | Yes |
| Connectivity & control | ||
| Connectivity | Wi-Fi, USB | Wi-Fi, USB |
| Wi-Fi | Yes | Yes |
| Ethernet | No | Yes |
| USB | Yes | Yes |
| SD card | No | No |
| Bluetooth | No | No |
| Cloud printing | Yes | — |
| Screen size | 4″ | 3.5″ |
| Touchscreen | No | Yes |
| Features | ||
| Built-in camera | Yes | Yes |
| Filament runout sensor | Yes | Yes |
| Power-loss recovery | — | Yes |
| Silent stepper drivers | — | Yes |
| Size & power | ||
| Width | 520 mm | 584 mm |
| Depth | 710 mm | 499 mm |
| Height | 443 mm | 730 mm |
| Weight | 14 kg | 18.2 kg |
| Rated power | 700 W | 1,150 W |
| Noise level | — | 50 dB |
