- Jupiter 2 vs Form Studio 1
Elegoo Jupiter 2 vs Formlabs Form Studio 1
What Jupiter 2 does better (4) and where Form Studio 1 wins (3) — every spec side by side.
vs
5.9Material versatility5.9
8.3Build volume6.0
7.6Ease of use9.4
Dimensions
Size comparison
Jupiter 2Form Studio 1
| Jupiter 2 | Form Studio 1 | Difference | |
|---|---|---|---|
| Height | 648.1 mm | 502 mm | +146.1 mm |
| Width | 465 mm | 342 mm | +123 mm |
| Depth | 508.1 mm | 315 mm | +193.1 mm |
| Weight | 28.9 kg | 14.3 kg | +14.6 kg |
Drawn to the same scale from the official dimensions (front and side).
Why is Jupiter 2 better than Form Studio 1?
- Build volume14.7 L vs 5.9 L2.5×
- Build height (Z)300 mm vs 235 mm+28%
- Build width (X)302 mm vs 200 mm+51%
- Build depth (Y)162 mm vs 125 mm+30%
Why is Form Studio 1 better than Jupiter 2?
- Camera resolution0.9 MP vs 2.1 MP2.3×
- Weight28.9 kg vs 14.3 kg2×
- Screen size4″ vs 7″+75%
Specifications
Side by side
| General | ||
| Technology | MSLA (LCD resin) | MSLA (LCD resin) |
| Delivered as | Fully assembled | Fully assembled |
| Build volume | ||
| Build width (X) | 302 mm | 200 mm |
| Build depth (Y) | 162 mm | 125 mm |
| Build height (Z) | 300 mm | 235 mm |
| Build volume | 14.7 L | 5.9 L |
| Speed | ||
| Resin print speed | 70 mm/h | — |
| Print quality | ||
| Finest layer height | 0.01 mm | — |
| Thickest layer height | 0.2 mm | — |
| Enclosure | ||
| Enclosed build chamber | Yes | Yes |
| Chamber light | — | Yes |
| Resin & LCD | ||
| LCD resolution class | 16K | — |
| LCD resolution (px) | 15120 × 6230 | — |
| LCD size | 14″ | — |
| XY resolution | 20 µm | — |
| Connectivity & control | ||
| Connectivity | Wi-Fi, USB | — |
| Wi-Fi | Yes | — |
| Ethernet | Yes | — |
| USB | Yes | — |
| SD card | No | — |
| Bluetooth | No | — |
| App control | — | Yes |
| Cloud printing | — | Yes |
| Screen size | 4″ | 7″ |
| Touchscreen | Yes | Yes |
| Features | ||
| Built-in camera | Yes | Yes |
| Camera resolution | 0.9 MP | 2.1 MP |
| Size & power | ||
| Width | 465 mm | 342 mm |
| Depth | 508 mm | 315 mm |
| Height | 648 mm | 502 mm |
| Weight | 28.9 kg | 14.3 kg |
| Rated power | 300 W | 300 W |
