Bambu Lab X1-Carbon vs JGAURORA A8S
What X1-Carbon does better (6) and where A8S wins (3) — every spec side by side.
Dimensions
Size comparison
X1-CarbonA8S
| X1-Carbon | A8S | Difference | |
|---|---|---|---|
| Height | 458 mm | 720 mm | −262 mm |
| Width | 386 mm | 740 mm | −354 mm |
| Depth | 389 mm | 560 mm | −171 mm |
| Weight | 13 kg | 32 kg | −19 kg |
Drawn to the same scale from the official dimensions (front and side).
Why is X1-Carbon better than A8S?
- Engineering materials (PA, PC, CF)Yes · A8S: No
- Max nozzle temperature300 °C vs 260 °C+15%
- Number of supported materials10 vs 42.5×
- Weight13 kg vs 32 kg2.5×
- Screen size5″ vs 4.3″+16%
- Build depth (Y)256 mm vs 250 mm+2%
Why is A8S better than X1-Carbon?
- Build volume16.8 L vs 26.2 L+56%
- Build height (Z)256 mm vs 300 mm+17%
- Build width (X)256 mm vs 350 mm+37%
Specifications
Side by side
| General | ||
| Technology | FDM / FFF (filament) | FDM / FFF (filament) |
| Motion system | CoreXY / XY-head | — |
| Delivered as | Fully assembled | Fully assembled |
| All-metal frame | Yes | — |
| Build volume | ||
| Build width (X) | 256 mm | 350 mm |
| Build depth (Y) | 256 mm | 250 mm |
| Build height (Z) | 256 mm | 300 mm |
| Build volume | 16.8 L | 26.2 L |
| Speed | ||
| Max print speed | 500 mm/s | — |
| Max acceleration | 20,000 mm/s² | — |
| Max volumetric flow | 32 mm³/s | — |
| Print quality | ||
| Finest layer height | 0.05 mm | 0.05 mm |
| Thickest layer height | 0.4 mm | 0.3 mm |
| Vibration compensation (input shaping) | Yes | — |
| Automatic bed levelling | Yes | — |
| Extruder & hotend | ||
| Max nozzle temperature | 300 °C | 260 °C |
| Direct-drive extruder | Yes | — |
| Default nozzle | 0.4 mm | 0.4 mm |
| Nozzle material | hardened steel | — |
| Swappable nozzle / hotend | Yes | — |
| Toolheads | 1 | — |
| Nozzles | 1 | — |
| Filament diameter | 1.75 mm | 1.75 mm |
| Filament cutter | Yes | — |
| Supported materials | ABS, ASA, Carbon, PA, PC, PET, PETG, PLA, PVA, TPU | ABS, PLA, TPU, etc |
| Number of supported materials | 10 | 4 |
| Engineering materials (PA, PC, CF) | Yes | No |
| Multi-colour | ||
| Multi-colour printing | Yes | — |
| Max colours / materials | 4 | — |
| Multi-colour system | AMS | — |
| Print bed | ||
| Heated bed | Yes | Yes |
| Max bed temperature | 110 °C | 110 °C |
| Flexible magnetic build plate | Yes | — |
| Enclosure | ||
| Enclosed build chamber | Yes | Yes |
| Air filter (carbon / HEPA) | Yes | — |
| Chamber light | Yes | — |
| Door sensor | Yes | — |
| Connectivity & control | ||
| Connectivity | Wi-Fi, SD card, Bluetooth | USB, SD card |
| Wi-Fi | Yes | — |
| Ethernet | No | — |
| USB | No | Yes |
| SD card | Yes | Yes |
| Bluetooth | Yes | — |
| App control | Yes | — |
| Screen size | 5″ | 4.3″ |
| Touchscreen | Yes | Yes |
| Features | ||
| Built-in camera | Yes | — |
| Camera resolution | 2.1 MP | — |
| Filament runout sensor | Yes | — |
| Power-loss recovery | Yes | — |
| Silent stepper drivers | Yes | — |
| Size & power | ||
| Width | 386 mm | 740 mm |
| Depth | 389 mm | 560 mm |
| Height | 458 mm | 720 mm |
| Weight | 13 kg | 32 kg |
| Rated power | 1,000 W | — |
