Bambu Lab H2D Pro vs CreatBot F430
What H2D Pro does better (5) and where F430 wins (7) — every spec side by side.
Dimensions
Size comparison
H2D ProF430
| H2D Pro | F430 | Difference | |
|---|---|---|---|
| Height | 626 mm | 680 mm | −54 mm |
| Width | 492 mm | 620 mm | −128 mm |
| Depth | 514 mm | 485 mm | +29 mm |
| Weight | 31 kg | 48 kg | −17 kg |
Drawn to the same scale from the official dimensions (front and side).
Why is H2D Pro better than F430?
- Max print speed600 mm/s vs 180 mm/s3.3×
- Build height (Z)325 mm vs 300 mm+8%
- Weight31 kg vs 48 kg+55%
- Screen size5″ vs 4.3″+16%
- Build depth (Y)320 mm vs 300 mm+7%
Why is F430 better than H2D Pro?
- Engineering materials (PA, PC, CF)No · H2D Pro: Yes
- Build volume31.2 L vs 36 L+15%
- Max nozzle temperature350 °C vs 420 °C+20%
- Number of supported materials4 vs 174.2×
- Max bed temperature120 °C vs 140 °C+17%
- Build width (X)300 mm vs 400 mm+33%
- Max chamber temperature65 °C vs 70 °C+8%
Specifications
Side by side
| General | ||
| Technology | FDM / FFF (filament) | FDM / FFF (filament) |
| Motion system | CoreXY / XY-head | — |
| Delivered as | Fully assembled | — |
| All-metal frame | Yes | — |
| Build volume | ||
| Build width (X) | 300 mm | 400 mm |
| Build depth (Y) | 320 mm | 300 mm |
| Build height (Z) | 325 mm | 300 mm |
| Build volume | 31.2 L | 36 L |
| Speed | ||
| Max print speed | 600 mm/s | 180 mm/s |
| Max acceleration | 20,000 mm/s² | — |
| Max volumetric flow | 40 mm³/s | — |
| Print quality | ||
| Finest layer height | — | 0.04 mm |
| Automatic bed levelling | Yes | Yes |
| Extruder & hotend | ||
| Max nozzle temperature | 350 °C | 420 °C |
| Direct-drive extruder | Yes | Yes |
| Default nozzle | 0.4 mm | 0.4 mm |
| Supported nozzle sizes (mm) | 0.2, 0.4, 0.6, 0.8 | — |
| Nozzle material | tungsten carbide | — |
| Swappable nozzle / hotend | Yes | — |
| Toolheads | 1 | — |
| Nozzles | 2 | 2 |
| Filament diameter | 1.75 mm | 1.75 mm |
| Filament cutter | Yes | — |
| Supported materials | ABS, PETG, PLA, TPU | PLA, ABS, Carbon Fiber, Wood, Nylon, PC, PETG, HIPS, PP, Flexible, TPU, PVA, UltraPA, PA-CF, PA-GF, ASA, PVDF |
| Number of supported materials | 4 | 17 |
| Engineering materials (PA, PC, CF) | No | Yes |
| Multi-colour | ||
| Multi-colour printing | Yes | — |
| Max colours / materials | 2 | — |
| Print bed | ||
| Heated bed | Yes | Yes |
| Max bed temperature | 120 °C | 140 °C |
| Enclosure | ||
| Enclosed build chamber | Yes | Yes |
| Actively heated chamber | Yes | Yes |
| Max chamber temperature | 65 °C | 70 °C |
| Air filter (carbon / HEPA) | Yes | Yes |
| Chamber light | Yes | — |
| Door sensor | Yes | — |
| Connectivity & control | ||
| Connectivity | Wi-Fi, USB | USB |
| Wi-Fi | Yes | — |
| Ethernet | Yes | — |
| USB | Yes | Yes |
| SD card | No | — |
| Bluetooth | No | — |
| App control | Yes | — |
| Screen size | 5″ | 4.3″ |
| Touchscreen | Yes | Yes |
| Features | ||
| Built-in camera | Yes | — |
| Filament runout sensor | — | Yes |
| Power-loss recovery | Yes | — |
| Laser engraving module | Yes | — |
| Size & power | ||
| Width | 492 mm | 620 mm |
| Depth | 514 mm | 485 mm |
| Height | 626 mm | 680 mm |
| Weight | 31 kg | 48 kg |
| Rated power | 2,200 W | 2,700 W |
