QIDI Plus 4 vs QIDI X-CF Pro
What Plus 4 does better (6) and where X-CF Pro wins (1) — every spec side by side.
Dimensions
Size comparison
Plus 4X-CF Pro
| Plus 4 | X-CF Pro | Difference | |
|---|---|---|---|
| Height | 550 mm | 678 mm | −128 mm |
| Width | 505 mm | 610 mm | −105 mm |
| Depth | 487 mm | 515 mm | −28 mm |
| Weight | 27 kg | 32.5 kg | −5.5 kg |
Drawn to the same scale from the official dimensions (front and side).
Why is Plus 4 better than X-CF Pro?
- Max print speed600 mm/s vs 60 mm/s10×
- Build volume26 L vs 22.5 L+16%
- Max nozzle temperature370 °C vs 350 °C+6%
- Build depth (Y)305 mm vs 250 mm+22%
- Weight27 kg vs 32.5 kg+20%
- Number of supported materials8 vs 7+14%
Why is X-CF Pro better than Plus 4?
- Build height (Z)280 mm vs 300 mm+7%
Specifications
Side by side
| General | ||
| Technology | FDM / FFF (filament) | FDM / FFF (filament) |
| Motion system | CoreXY / XY-head | — |
| Delivered as | Fully assembled | — |
| Klipper firmware | Yes | — |
| Build volume | ||
| Build width (X) | 305 mm | 300 mm |
| Build depth (Y) | 305 mm | 250 mm |
| Build height (Z) | 280 mm | 300 mm |
| Build volume | 26 L | 22.5 L |
| Speed | ||
| Max print speed | 600 mm/s | 60 mm/s |
| Max acceleration | 20,000 mm/s² | — |
| Print quality | ||
| Finest layer height | 0.05 mm | 0.05 mm |
| Thickest layer height | 0.4 mm | — |
| Vibration compensation (input shaping) | Yes | — |
| Automatic bed levelling | Yes | — |
| Extruder & hotend | ||
| Max nozzle temperature | 370 °C | 350 °C |
| Direct-drive extruder | Yes | — |
| Default nozzle | 0.4 mm | 0.4 mm |
| Supported nozzle sizes (mm) | 0.4, 0.8 | — |
| Swappable nozzle / hotend | Yes | — |
| Toolheads | 1 | — |
| Nozzles | 1 | — |
| Filament diameter | 1.75 mm | 1.75 mm |
| Filament cutter | Yes | — |
| Supported materials | ABS, ASA, Carbon, PA, PC, PETG, PLA, TPU | PA12-CF, PLA, ABS, TPU, PETG, Nylon, PC |
| Number of supported materials | 8 | 7 |
| Engineering materials (PA, PC, CF) | Yes | Yes |
| Print bed | ||
| Heated bed | Yes | Yes |
| Max bed temperature | 120 °C | 120 °C |
| Flexible magnetic build plate | Yes | — |
| Enclosure | ||
| Enclosed build chamber | Yes | Yes |
| Actively heated chamber | Yes | — |
| Max chamber temperature | 65 °C | — |
| Air filter (carbon / HEPA) | Yes | — |
| Chamber light | Yes | — |
| Connectivity & control | ||
| Connectivity | Wi-Fi, Ethernet, USB | Wi-Fi, Ethernet, USB |
| Wi-Fi | Yes | Yes |
| Ethernet | Yes | Yes |
| USB | Yes | Yes |
| Screen size | 5″ | 5″ |
| Touchscreen | Yes | Yes |
| Features | ||
| Built-in camera | Yes | — |
| Camera resolution | 2.1 MP | — |
| Filament runout sensor | Yes | — |
| Power-loss recovery | Yes | — |
| Silent stepper drivers | Yes | — |
| Size & power | ||
| Width | 505 mm | 610 mm |
| Depth | 487 mm | 515 mm |
| Height | 550 mm | 678 mm |
| Weight | 27 kg | 32.5 kg |
| Rated power | 450 W | — |
