Flashforge Creator 5 Pro vs QIDI Plus5
What Creator 5 Pro does better (2) and where Plus5 wins (7) — every spec side by side.
vs
7.4Material versatility8.1
6.0Build volume8.4
8.2Ease of use4.6
Dimensions
Size comparison
Creator 5 ProPlus5
| Creator 5 Pro | Plus5 | Difference | |
|---|---|---|---|
| Height | 710 mm | 558 mm | +152 mm |
| Width | 520 mm | 500 mm | +20 mm |
| Depth | 443 mm | 488 mm | −45 mm |
| Weight | 18 kg | 29 kg | −11 kg |
Drawn to the same scale from the official dimensions (front and side).
Why is Creator 5 Pro better than Plus5?
- Number of supported materials3 vs 13×
- Weight18 kg vs 29 kg+61%
Why is Plus5 better than Creator 5 Pro?
- Build volume16.8 L vs 30.7 L+83%
- Max print speed300 mm/s vs 600 mm/s2×
- Max nozzle temperature320 °C vs 370 °C+16%
- EthernetNo · Creator 5 Pro: Yes
- Build height (Z)256 mm vs 300 mm+17%
- Build width (X)256 mm vs 320 mm+25%
- Build depth (Y)256 mm vs 320 mm+25%
Specifications
Side by side
| General | ||
| Technology | FDM / FFF (filament) | FDM / FFF (filament) |
| Motion system | CoreXY / XY-head | CoreXY / XY-head |
| Delivered as | — | Fully assembled |
| Build volume | ||
| Build width (X) | 256 mm | 320 mm |
| Build depth (Y) | 256 mm | 320 mm |
| Build height (Z) | 256 mm | 300 mm |
| Build volume | 16.8 L | 30.7 L |
| Speed | ||
| Max print speed | 300 mm/s | 600 mm/s |
| Max acceleration | — | 20,000 mm/s² |
| Print quality | ||
| Vibration compensation (input shaping) | — | Yes |
| Automatic bed levelling | Yes | Yes |
| Extruder & hotend | ||
| Max nozzle temperature | 320 °C | 370 °C |
| Direct-drive extruder | — | Yes |
| Default nozzle | 0.4 mm | 0.4 mm |
| Supported nozzle sizes (mm) | — | 0.4, 0.8 |
| Swappable nozzle / hotend | — | Yes |
| Toolheads | — | 1 |
| Nozzles | — | 1 |
| Filament diameter | — | 1.75 mm |
| Filament cutter | — | Yes |
| Supported materials | PLA, PETG, TPU | PLA |
| Number of supported materials | 3 | 1 |
| Engineering materials (PA, PC, CF) | No | No |
| Multi-colour | ||
| Multi-colour printing | Yes | Yes |
| Max colours / materials | — | 16 |
| Multi-colour system | — | QIDI Box |
| Print bed | ||
| Heated bed | Yes | Yes |
| Max bed temperature | 120 °C | 120 °C |
| Enclosure | ||
| Enclosed build chamber | — | Yes |
| Actively heated chamber | — | Yes |
| Max chamber temperature | — | 65 °C |
| Air filter (carbon / HEPA) | — | Yes |
| Connectivity & control | ||
| Connectivity | Wi-Fi, USB | Wi-Fi, Ethernet, USB |
| Wi-Fi | Yes | Yes |
| Ethernet | No | Yes |
| USB | Yes | Yes |
| SD card | No | No |
| Bluetooth | No | No |
| App control | — | Yes |
| Cloud printing | — | Yes |
| Screen size | — | 4″ |
| Touchscreen | Yes | Yes |
| Features | ||
| Built-in camera | Yes | Yes |
| Filament runout sensor | — | Yes |
| Power-loss recovery | — | Yes |
| Size & power | ||
| Width | 520 mm | 500 mm |
| Depth | 443 mm | 488 mm |
| Height | 710 mm | 558 mm |
| Weight | 18 kg | 29 kg |
| Rated power | — | 550 W |
