- Stellar 2 vs Sonic Mega 8K V2
Emake3D Stellar 2 vs Phrozen Sonic Mega 8K V2
What Stellar 2 does better (6) and where Sonic Mega 8K V2 wins (4) — every spec side by side.
vs
3.8Print quality6.2
9.1Build volume9.2
8.5Ease of use4.8
Dimensions
Size comparison
Stellar 2Sonic Mega 8K V2
| Stellar 2 | Sonic Mega 8K V2 | Difference | |
|---|---|---|---|
| Height | 1,645.5 mm | 680 mm | +965.5 mm |
| Width | 490 mm | 470 mm | +20 mm |
| Depth | 438.5 mm | 400 mm | +38.5 mm |
| Weight | 95 kg | 42 kg | +53 kg |
Drawn to the same scale from the official dimensions (front and side).
Why is Stellar 2 better than Sonic Mega 8K V2?
- Wi-FiYes · Sonic Mega 8K V2: No
- Build volume26.6 L vs 24.4 L+9%
- EthernetYes · Sonic Mega 8K V2: No
- Build depth (Y)198 mm vs 185 mm+7%
- Build width (X)353 mm vs 330 mm+7%
- LCD size16″ vs 15″+7%
Why is Sonic Mega 8K V2 better than Stellar 2?
- Finest layer height0.025 mm vs 0.01 mm2.5×
- XY resolution46 µm vs 43 µm+7%
- Weight95 kg vs 42 kg2.3×
- Build height (Z)380 mm vs 400 mm+5%
Specifications
Side by side
| General | ||
| Technology | MSLA (LCD resin) | MSLA (LCD resin) |
| Delivered as | — | Fully assembled |
| Build volume | ||
| Build width (X) | 353 mm | 330 mm |
| Build depth (Y) | 198 mm | 185 mm |
| Build height (Z) | 380 mm | 400 mm |
| Build volume | 26.6 L | 24.4 L |
| Speed | ||
| Resin print speed | 90 mm/h | — |
| Print quality | ||
| Finest layer height | 0.025 mm | 0.01 mm |
| Thickest layer height | 0.1 mm | 0.3 mm |
| Enclosure | ||
| Max chamber temperature | 40 °C | — |
| Air filter (carbon / HEPA) | — | Yes |
| Resin & LCD | ||
| LCD resolution class | 8K | 8K |
| LCD size | 16″ | 15″ |
| XY resolution | 46 µm | 43 µm |
| Connectivity & control | ||
| Connectivity | Wi-Fi, Ethernet, USB | USB |
| Wi-Fi | Yes | No |
| Ethernet | Yes | No |
| USB | Yes | Yes |
| SD card | — | No |
| Bluetooth | — | No |
| Screen size | 5″ | 5″ |
| Touchscreen | Yes | Yes |
| Size & power | ||
| Width | 490 mm | 470 mm |
| Depth | 438 mm | 400 mm |
| Height | 1,646 mm | 680 mm |
| Weight | 95 kg | 42 kg |
| Rated power | 250 W | 240 W |
