- LD-002R vs Mars 3
Creality LD-002R vs Elegoo Mars 3
What LD-002R does better (0) and where Mars 3 wins (6) — every spec side by side.
Dimensions
Size comparison
LD-002RMars 3
| LD-002R | Mars 3 | Difference | |
|---|---|---|---|
| Height | 403 mm | 438.5 mm | −35.5 mm |
| Width | 221 mm | 227 mm | −6 mm |
| Depth | 221 mm | 227 mm | −6 mm |
| Weight | 7 kg | 5.2 kg | +1.8 kg |
Drawn to the same scale from the official dimensions (front and side).
Why is LD-002R better than Mars 3?
LD-002R has no measurable advantages in this pair.
Why is Mars 3 better than LD-002R?
- Build volume1.2 L vs 2.3 L+92%
- Finest layer height0.05 mm vs 0.01 mm5×
- Build height (Z)160 mm vs 175 mm+9%
- Build depth (Y)65 mm vs 90 mm+38%
- Weight7 kg vs 5.2 kg+35%
- Build width (X)119 mm vs 143 mm+20%
Specifications
Side by side
| General | ||
| Technology | MSLA (LCD resin) | MSLA (LCD resin) |
| Delivered as | — | Fully assembled |
| Build volume | ||
| Build width (X) | 119 mm | 143 mm |
| Build depth (Y) | 65 mm | 90 mm |
| Build height (Z) | 160 mm | 175 mm |
| Build volume | 1.2 L | 2.3 L |
| Speed | ||
| Resin print speed | — | 50 mm/h |
| Print quality | ||
| Finest layer height | 0.05 mm | 0.01 mm |
| Thickest layer height | — | 0.2 mm |
| Enclosure | ||
| Enclosed build chamber | — | Yes |
| Resin & LCD | ||
| LCD resolution class | — | 4K |
| LCD resolution (px) | — | 4098 × 2560 |
| LCD size | — | 6.6″ |
| XY resolution | — | 35 µm |
| Connectivity & control | ||
| Connectivity | USB | USB |
| Wi-Fi | No | No |
| Ethernet | No | No |
| USB | Yes | Yes |
| SD card | No | No |
| Bluetooth | No | No |
| Screen size | — | 3.5″ |
| Touchscreen | — | Yes |
| Features | ||
| Built-in camera | — | No |
| Size & power | ||
| Width | 221 mm | 227 mm |
| Depth | 221 mm | 227 mm |
| Height | 403 mm | 438 mm |
| Weight | 7 kg | 5.2 kg |
| Rated power | 72 W | 60 W |
