- K1 vs AD5X
Creality K1 vs Flashforge AD5X
What K1 does better (5) and where AD5X wins (4) — every spec side by side.
Dimensions
Size comparison
K1AD5X
| K1 | AD5X | Difference | |
|---|---|---|---|
| Height | 480 mm | 448 mm | +32 mm |
| Width | 355 mm | 363 mm | −8 mm |
| Depth | 355 mm | 402 mm | −47 mm |
| Weight | 12.5 kg | 12.2 kg | +0.3 kg |
Drawn to the same scale from the official dimensions (front and side).
Why is K1 better than AD5X?
- Max print speed600 mm/s vs 300 mm/s2×
- Build volume12.1 L vs 8.8 L+37%
- Build height (Z)250 mm vs 200 mm+25%
- Number of supported materials5 vs 3+67%
- Build depth (Y)220 mm vs 200 mm+10%
Why is AD5X better than K1?
- Finest layer height0.1 mm vs 0.05 mm2×
- EthernetNo · K1: Yes
- Max bed temperature100 °C vs 110 °C+10%
- Weight12.5 kg vs 12.2 kg+2%
Specifications
Side by side
| General | ||
| Technology | FDM / FFF (filament) | FDM / FFF (filament) |
| Motion system | CoreXY / XY-head | CoreXY / XY-head |
| Delivered as | — | Partially assembled |
| Build volume | ||
| Build width (X) | 220 mm | 220 mm |
| Build depth (Y) | 220 mm | 200 mm |
| Build height (Z) | 250 mm | 200 mm |
| Build volume | 12.1 L | 8.8 L |
| Speed | ||
| Max print speed | 600 mm/s | 300 mm/s |
| Max acceleration | 20,000 mm/s² | 20,000 mm/s² |
| Print quality | ||
| Finest layer height | 0.1 mm | 0.05 mm |
| Thickest layer height | 0.35 mm | 0.4 mm |
| Vibration compensation (input shaping) | Yes | — |
| Automatic bed levelling | Yes | Yes |
| Extruder & hotend | ||
| Max nozzle temperature | 300 °C | 300 °C |
| Default nozzle | 0.4 mm | 0.4 mm |
| Supported nozzle sizes (mm) | — | 0.4, 0.8 |
| Nozzle material | hardened steel | — |
| Toolheads | — | 1 |
| Nozzles | — | 1 |
| Filament diameter | 1.75 mm | 1.75 mm |
| Supported materials | ABS, PLA, PETG, PET, TPU | PETG, PLA, TPU |
| Number of supported materials | 5 | 3 |
| Engineering materials (PA, PC, CF) | No | No |
| Multi-colour | ||
| Multi-colour printing | — | Yes |
| Max colours / materials | — | 4 |
| Multi-colour system | — | IFS |
| Print bed | ||
| Heated bed | Yes | Yes |
| Max bed temperature | 100 °C | 110 °C |
| Enclosure | ||
| Enclosed build chamber | Yes | — |
| Air filter (carbon / HEPA) | Yes | — |
| Chamber light | Yes | Yes |
| Connectivity & control | ||
| Connectivity | Wi-Fi, USB | Wi-Fi, Ethernet, USB |
| Wi-Fi | Yes | Yes |
| Ethernet | No | Yes |
| USB | Yes | Yes |
| SD card | No | No |
| Bluetooth | No | No |
| App control | Yes | — |
| Screen size | 4.3″ | 4.3″ |
| Touchscreen | Yes | Yes |
| Features | ||
| Filament runout sensor | Yes | Yes |
| Power-loss recovery | Yes | Yes |
| Size & power | ||
| Width | 355 mm | 363 mm |
| Depth | 355 mm | 402 mm |
| Height | 480 mm | 448 mm |
| Weight | 12.5 kg | 12.2 kg |
| Rated power | 350 W | 650 W |
