Creality CR-30 Printmill Belt vs Tiertime X5
What CR-30 Printmill Belt does better (1) and where X5 wins (2) — every spec side by side.
vs
Dimensions
Size comparison
CR-30 Printmill BeltX5
| CR-30 Printmill Belt | X5 | Difference | |
|---|---|---|---|
| Height | 410 mm | 520 mm | −110 mm |
| Width | 535 mm | 850 mm | −315 mm |
| Depth | 656 mm | 625 mm | +31 mm |
| Weight | 16.5 kg | 52 kg | −35.5 kg |
Drawn to the same scale from the official dimensions (front and side).
Why is CR-30 Printmill Belt better than X5?
- Weight16.5 kg vs 52 kg3.2×
Why is X5 better than CR-30 Printmill Belt?
- Wi-FiNo · CR-30 Printmill Belt: Yes
- EthernetNo · CR-30 Printmill Belt: Yes
Specifications
Side by side
| General | ||
| Technology | FDM / FFF (filament) | FDM / FFF (filament) |
| Delivered as | — | Fully assembled |
| Build volume | ||
| Build width (X) | — | 180 mm |
| Build depth (Y) | — | 230 mm |
| Build height (Z) | — | 200 mm |
| Build volume | — | 8.3 L |
| Speed | ||
| Max print speed | — | 200 mm/s |
| Print quality | ||
| Finest layer height | — | 0.05 mm |
| Thickest layer height | — | 0.4 mm |
| Extruder & hotend | ||
| Max nozzle temperature | — | 299 °C |
| Default nozzle | 0.4 mm | 0.5 mm |
| Filament diameter | 1.75 mm | 1.75 mm |
| Supported materials | PLA, TPU, PETG | — |
| Number of supported materials | 3 | — |
| Engineering materials (PA, PC, CF) | No | — |
| Connectivity & control | ||
| Connectivity | USB, SD card | Wi-Fi, Ethernet, USB |
| Wi-Fi | No | Yes |
| Ethernet | No | Yes |
| USB | Yes | Yes |
| SD card | Yes | — |
| Bluetooth | No | — |
| Screen size | — | 7″ |
| Touchscreen | — | Yes |
| Size & power | ||
| Width | 535 mm | 850 mm |
| Depth | 656 mm | 625 mm |
| Height | 410 mm | 520 mm |
| Weight | 16.5 kg | 52 kg |
| Rated power | 350 W | — |
