Creality CR-30 Printmill Belt vs Fusion3 Edge
What CR-30 Printmill Belt does better (1) and where Edge wins (4) — every spec side by side.
vs
Dimensions
Size comparison
CR-30 Printmill BeltEdge
| CR-30 Printmill Belt | Edge | Difference | |
|---|---|---|---|
| Height | 410 mm | 640 mm | −230 mm |
| Width | 535 mm | 657 mm | −122 mm |
| Depth | 656 mm | 720 mm | −64 mm |
| Weight | 16.5 kg | 38.6 kg | −22.1 kg |
Drawn to the same scale from the official dimensions (front and side).
Why is CR-30 Printmill Belt better than Edge?
- Weight16.5 kg vs 38.6 kg2.3×
Why is Edge better than CR-30 Printmill Belt?
- Engineering materials (PA, PC, CF)No · CR-30 Printmill Belt: Yes
- Wi-FiNo · CR-30 Printmill Belt: Yes
- Number of supported materials3 vs 144.7×
- EthernetNo · CR-30 Printmill Belt: Yes
Specifications
Side by side
| General | ||
| Technology | FDM / FFF (filament) | FDM / FFF (filament) |
| Build volume | ||
| Build width (X) | — | 368 mm |
| Build depth (Y) | — | 368 mm |
| Build height (Z) | — | 343 mm |
| Build volume | — | 46.5 L |
| Speed | ||
| Max print speed | — | 250 mm/s |
| Print quality | ||
| Finest layer height | — | 0.02 mm |
| Extruder & hotend | ||
| Default nozzle | 0.4 mm | 0.4 mm |
| Supported nozzle sizes (mm) | — | 0.4, 0.6, 0.8 |
| Filament diameter | 1.75 mm | 1.75 mm |
| Supported materials | PLA, TPU, PETG | PLA, ABS, ASA, Carbon Fiber, Kevlar, Fiberglass, Flexible, Nylons, PET, PETG, Polycarbonate, Polypropylene, PVDF, etc. |
| Number of supported materials | 3 | 14 |
| Engineering materials (PA, PC, CF) | No | Yes |
| Print bed | ||
| Heated bed | — | Yes |
| Max bed temperature | — | 140 °C |
| Enclosure | ||
| Actively heated chamber | — | Yes |
| Max chamber temperature | — | 70 °C |
| Connectivity & control | ||
| Connectivity | USB, SD card | Wi-Fi, Ethernet, USB, Bluetooth |
| Wi-Fi | No | Yes |
| Ethernet | No | Yes |
| USB | Yes | Yes |
| SD card | Yes | — |
| Bluetooth | No | Yes |
| Screen size | — | 7″ |
| Touchscreen | — | Yes |
| Size & power | ||
| Width | 535 mm | 657 mm |
| Depth | 656 mm | 720 mm |
| Height | 410 mm | 640 mm |
| Weight | 16.5 kg | 38.6 kg |
| Rated power | 350 W | — |
