Bambu Lab H2S vs QIDI X-MAX 3
What H2S does better (5) and where X-MAX 3 wins (1) — every spec side by side.
Dimensions
Size comparison
H2SX-MAX 3
| H2S | X-MAX 3 | Difference | |
|---|---|---|---|
| Height | 626 mm | 601 mm | +25 mm |
| Width | 492 mm | 553 mm | −61 mm |
| Depth | 514 mm | 553 mm | −39 mm |
| Weight | 30 kg | 30.2 kg | −0.2 kg |
Drawn to the same scale from the official dimensions (front and side).
Why is H2S better than X-MAX 3?
- Max print speed1,000 mm/s vs 600 mm/s+67%
- Max volumetric flow65 mm³/s vs 35 mm³/s+86%
- Build volume37 L vs 33.3 L+11%
- Build width (X)340 mm vs 325 mm+5%
- Build depth (Y)340 mm vs 325 mm+5%
Why is X-MAX 3 better than H2S?
- EthernetNo · H2S: Yes
Specifications
Side by side
| General | ||
| Technology | FDM / FFF (filament) | FDM / FFF (filament) |
| Motion system | CoreXY / XY-head | CoreXY / XY-head |
| Delivered as | Fully assembled | — |
| All-metal frame | Yes | — |
| Klipper firmware | — | Yes |
| Build volume | ||
| Build width (X) | 340 mm | 325 mm |
| Build depth (Y) | 340 mm | 325 mm |
| Build height (Z) | 320 mm | 315 mm |
| Build volume | 37 L | 33.3 L |
| Speed | ||
| Max print speed | 1,000 mm/s | 600 mm/s |
| Max acceleration | 20,000 mm/s² | 20,000 mm/s² |
| Max volumetric flow | 65 mm³/s | 35 mm³/s |
| Print quality | ||
| Finest layer height | — | 0.1 mm |
| Vibration compensation (input shaping) | — | Yes |
| Automatic bed levelling | — | Yes |
| Extruder & hotend | ||
| Max nozzle temperature | 350 °C | 350 °C |
| Direct-drive extruder | Yes | — |
| Default nozzle | 0.4 mm | 0.4 mm |
| Supported nozzle sizes (mm) | — | 0.4, 0.8 |
| Nozzle material | steel | hardened steel |
| Swappable nozzle / hotend | Yes | — |
| Toolheads | 1 | — |
| Nozzles | 1 | — |
| Filament diameter | 1.75 mm | 1.75 mm |
| Supported materials | ABS, PETG, PLA, TPU | — |
| Number of supported materials | 4 | — |
| Engineering materials (PA, PC, CF) | No | — |
| Multi-colour | ||
| Multi-colour printing | Yes | — |
| Max colours / materials | 4 | — |
| Multi-colour system | AMS | — |
| Print bed | ||
| Heated bed | Yes | Yes |
| Max bed temperature | 120 °C | 120 °C |
| Enclosure | ||
| Enclosed build chamber | Yes | — |
| Actively heated chamber | Yes | Yes |
| Max chamber temperature | 65 °C | 65 °C |
| Air filter (carbon / HEPA) | Yes | — |
| Chamber light | Yes | — |
| Door sensor | Yes | — |
| Connectivity & control | ||
| Connectivity | Wi-Fi, USB | Wi-Fi, Ethernet, USB |
| Wi-Fi | Yes | Yes |
| Ethernet | No | Yes |
| USB | Yes | Yes |
| SD card | No | — |
| Bluetooth | No | — |
| App control | Yes | — |
| Screen size | 5″ | 5″ |
| Touchscreen | Yes | Yes |
| Features | ||
| Built-in camera | Yes | — |
| Camera resolution | 2.1 MP | — |
| Filament runout sensor | — | Yes |
| Power-loss recovery | Yes | — |
| Laser engraving module | Yes | — |
| Size & power | ||
| Width | 492 mm | 553 mm |
| Depth | 514 mm | 553 mm |
| Height | 626 mm | 601 mm |
| Weight | 30 kg | 30.2 kg |
| Rated power | 2,050 W | 900 W |
