Bambu Lab H2C vs Bambu Lab H2D
What H2C does better (3) and where H2D wins (2) — every spec side by side.
Dimensions
Size comparison
H2CH2D
| H2C | H2D | Difference | |
|---|---|---|---|
| Height | 626 mm | 626 mm | = |
| Width | 492 mm | 492 mm | = |
| Depth | 514 mm | 514 mm | = |
| Weight | 32.5 kg | 31 kg | +1.5 kg |
Drawn to the same scale from the official dimensions (front and side).
Why is H2C better than H2D?
- Max print speed1,000 mm/s vs 600 mm/s+67%
- Engineering materials (PA, PC, CF)Yes · H2D: No
- Number of supported materials12 vs 43×
Why is H2D better than H2C?
- Max volumetric flow40 mm³/s vs 65 mm³/s+62%
- Weight32.5 kg vs 31 kg+5%
Specifications
Side by side
| General | ||
| Technology | FDM / FFF (filament) | FDM / FFF (filament) |
| Motion system | CoreXY / XY-head | CoreXY / XY-head |
| Delivered as | Fully assembled | Fully assembled |
| All-metal frame | Yes | Yes |
| Build volume | ||
| Build width (X) | 300 mm | 300 mm |
| Build depth (Y) | 320 mm | 320 mm |
| Build height (Z) | 325 mm | 325 mm |
| Build volume | 31.2 L | 31.2 L |
| Speed | ||
| Max print speed | 1,000 mm/s | 600 mm/s |
| Max acceleration | 20,000 mm/s² | 20,000 mm/s² |
| Max volumetric flow | 40 mm³/s | 65 mm³/s |
| Print quality | ||
| Automatic bed levelling | — | Yes |
| Extruder & hotend | ||
| Max nozzle temperature | 350 °C | 350 °C |
| Direct-drive extruder | Yes | Yes |
| Default nozzle | 0.4 mm | 0.4 mm |
| Nozzle material | hardened steel | steel |
| Swappable nozzle / hotend | Yes | Yes |
| Toolheads | 1 | 1 |
| Nozzles | 2 | 2 |
| Filament diameter | 1.75 mm | 1.75 mm |
| Filament cutter | Yes | — |
| Supported materials | ABS, ASA, BVOH, PA, PA-CF, PA-GF, PET, PETG, PLA, PPS, PVA, TPU | ABS, PETG, PLA, TPU |
| Number of supported materials | 12 | 4 |
| Engineering materials (PA, PC, CF) | Yes | No |
| Multi-colour | ||
| Multi-colour printing | Yes | Yes |
| Max colours / materials | 4 | 4 |
| Multi-colour system | AMS | AMS |
| Print bed | ||
| Heated bed | Yes | Yes |
| Max bed temperature | 120 °C | 120 °C |
| Enclosure | ||
| Enclosed build chamber | Yes | Yes |
| Actively heated chamber | Yes | Yes |
| Max chamber temperature | 65 °C | 65 °C |
| Air filter (carbon / HEPA) | Yes | Yes |
| Chamber light | Yes | Yes |
| Door sensor | Yes | Yes |
| Connectivity & control | ||
| Connectivity | Wi-Fi, USB | Wi-Fi, USB |
| Wi-Fi | Yes | Yes |
| Ethernet | No | — |
| USB | Yes | Yes |
| SD card | No | — |
| Bluetooth | No | — |
| App control | Yes | Yes |
| Screen size | 5″ | 5″ |
| Touchscreen | Yes | Yes |
| Features | ||
| Built-in camera | Yes | Yes |
| Camera resolution | — | 2.1 MP |
| Power-loss recovery | Yes | Yes |
| Laser engraving module | Yes | Yes |
| Size & power | ||
| Width | 492 mm | 492 mm |
| Depth | 514 mm | 514 mm |
| Height | 626 mm | 626 mm |
| Weight | 32.5 kg | 31 kg |
| Rated power | 1,800 W | 2,200 W |
