Bambu Lab A1 mini vs Geeetech M1
What A1 mini does better (7) and where M1 wins (1) — every spec side by side.
Dimensions
Size comparison
A1 miniM1
| A1 mini | M1 | Difference | |
|---|---|---|---|
| Height | 315 mm | 298 mm | +17 mm |
| Width | 347 mm | 279 mm | +68 mm |
| Depth | 365 mm | 200 mm | +165 mm |
| Weight | 5.5 kg | 3 kg | +2.5 kg |
Drawn to the same scale from the official dimensions (front and side).
Why is A1 mini better than M1?
- Build volume5.8 L vs 1.1 L5.3×
- Max print speed500 mm/s vs 250 mm/s2×
- Build height (Z)180 mm vs 110 mm+64%
- Max bed temperature80 °C vs 60 °C+33%
- TouchscreenYes · M1: No
- Build width (X)180 mm vs 100 mm+80%
- Build depth (Y)180 mm vs 100 mm+80%
Why is M1 better than A1 mini?
- Weight5.5 kg vs 3 kg+83%
Specifications
Side by side
| General | ||
| Technology | FDM / FFF (filament) | FDM / FFF (filament) |
| Motion system | Bed-slinger (i3-style) | Bed-slinger (i3-style) |
| Delivered as | Fully assembled | — |
| All-metal frame | Yes | — |
| Build volume | ||
| Build width (X) | 180 mm | 100 mm |
| Build depth (Y) | 180 mm | 100 mm |
| Build height (Z) | 180 mm | 110 mm |
| Build volume | 5.8 L | 1.1 L |
| Speed | ||
| Max print speed | 500 mm/s | 250 mm/s |
| Max acceleration | 10,000 mm/s² | — |
| Max volumetric flow | 28 mm³/s | — |
| Print quality | ||
| Finest layer height | — | 0.1 mm |
| Thickest layer height | — | 0.2 mm |
| Vibration compensation (input shaping) | Yes | — |
| Automatic bed levelling | Yes | — |
| Extruder & hotend | ||
| Max nozzle temperature | 300 °C | — |
| Direct-drive extruder | Yes | Yes |
| Default nozzle | 0.4 mm | 0.4 mm |
| Nozzle material | stainless steel | — |
| Swappable nozzle / hotend | Yes | — |
| Toolheads | 1 | 1 |
| Nozzles | 1 | 1 |
| Filament diameter | 1.75 mm | 1.75 mm |
| Filament cutter | Yes | — |
| Supported materials | PETG, PLA, PVA, TPU | — |
| Number of supported materials | 4 | — |
| Engineering materials (PA, PC, CF) | No | — |
| Multi-colour | ||
| Multi-colour printing | Yes | — |
| Max colours / materials | 4 | — |
| Multi-colour system | AMS lite | — |
| Print bed | ||
| Heated bed | Yes | Yes |
| Max bed temperature | 80 °C | 60 °C |
| Flexible magnetic build plate | Yes | — |
| Enclosure | ||
| Actively heated chamber | No | — |
| Chamber light | Yes | — |
| Connectivity & control | ||
| Connectivity | Wi-Fi, SD card | USB, SD card |
| Wi-Fi | Yes | — |
| Ethernet | Yes | — |
| USB | — | Yes |
| SD card | Yes | Yes |
| App control | Yes | — |
| Screen size | 2.4″ | — |
| Touchscreen | Yes | No |
| Features | ||
| Built-in camera | Yes | — |
| Camera resolution | 2.1 MP | — |
| Filament runout sensor | Yes | — |
| Power-loss recovery | Yes | — |
| Silent stepper drivers | Yes | — |
| Size & power | ||
| Width | 347 mm | 279 mm |
| Depth | 365 mm | 200 mm |
| Height | 315 mm | 298 mm |
| Weight | 5.5 kg | 3 kg |
| Rated power | 150 W | — |
