- Photon Mono M7 Max vs Saturn 4 Ultra
Anycubic Photon Mono M7 Max vs Elegoo Saturn 4 Ultra
What Photon Mono M7 Max does better (7) and where Saturn 4 Ultra wins (5) — every spec side by side.
vs
4.3Speed7.1
5.0Print quality8.4
5.9Material versatility5.9
8.3Build volume5.8
5.3Ease of use7.6
Dimensions
Size comparison
Photon Mono M7 MaxSaturn 4 Ultra
| Photon Mono M7 Max | Saturn 4 Ultra | Difference | |
|---|---|---|---|
| Height | 652 mm | 548 mm | +104 mm |
| Width | 425 mm | 329 mm | +96 mm |
| Depth | 362 mm | 327 mm | +35 mm |
| Weight | 24 kg | 14.5 kg | +9.5 kg |
Drawn to the same scale from the official dimensions (front and side).
Why is Photon Mono M7 Max better than Saturn 4 Ultra?
- Build volume14.7 L vs 5.9 L2.5×
- Build height (Z)300 mm vs 220 mm+36%
- Delivered asFully assembled vs Partially assembled
- Build width (X)298 mm vs 219 mm+36%
- LCD size13.6″ vs 10″+36%
- Build depth (Y)164 mm vs 123 mm+33%
- Screen size4.3″ vs 4″+7%
Why is Saturn 4 Ultra better than Photon Mono M7 Max?
- Resin print speed63 mm/h vs 150 mm/h2.4×
- XY resolution46 µm vs 24 µm+92%
- LCD resolution class7K vs 12K+71%
- Built-in cameraNo · Photon Mono M7 Max: Yes
- Weight24 kg vs 14.5 kg+66%
Specifications
Side by side
| General | ||
| Technology | MSLA (LCD resin) | MSLA (LCD resin) |
| Delivered as | Fully assembled | Partially assembled |
| Build volume | ||
| Build width (X) | 298 mm | 219 mm |
| Build depth (Y) | 164 mm | 123 mm |
| Build height (Z) | 300 mm | 220 mm |
| Build volume | 14.7 L | 5.9 L |
| Speed | ||
| Resin print speed | 63 mm/h | 150 mm/h |
| Print quality | ||
| Finest layer height | 0.01 mm | 0.01 mm |
| Thickest layer height | 0.15 mm | 0.2 mm |
| Enclosure | ||
| Enclosed build chamber | Yes | Yes |
| Air filter (carbon / HEPA) | Yes | — |
| Resin & LCD | ||
| LCD resolution class | 7K | 12K |
| LCD resolution (px) | 6480 × 3600 | 11520 × 5120 |
| LCD size | 13.6″ | 10″ |
| XY resolution | 46 µm | 24 µm |
| Connectivity & control | ||
| Connectivity | Wi-Fi, USB | Wi-Fi, USB, Ethernet |
| Wi-Fi | Yes | Yes |
| Ethernet | Yes | Yes |
| USB | Yes | Yes |
| SD card | No | No |
| Bluetooth | No | No |
| App control | Yes | — |
| Screen size | 4.3″ | 4″ |
| Touchscreen | Yes | Yes |
| Features | ||
| Built-in camera | No | Yes |
| Size & power | ||
| Width | 425 mm | 329 mm |
| Depth | 362 mm | 327 mm |
| Height | 652 mm | 548 mm |
| Weight | 24 kg | 14.5 kg |
| Rated power | 180 W | — |
