Gembird 3DP-GEMMA vs Makeblock mCreate
What 3DP-GEMMA does better (1) and where mCreate wins (6) — every spec side by side.
Dimensions
Size comparison
3DP-GEMMAmCreate
| 3DP-GEMMA | mCreate | Difference | |
|---|---|---|---|
| Height | 290 mm | 550 mm | −260 mm |
| Width | 210 mm | 445 mm | −235 mm |
| Depth | 210 mm | 485 mm | −275 mm |
| Weight | 3 kg | 11 kg | −8 kg |
Drawn to the same scale from the official dimensions (front and side).
Why is 3DP-GEMMA better than mCreate?
- Weight3 kg vs 11 kg3.7×
Why is mCreate better than 3DP-GEMMA?
- Build volume1.3 L vs 14.3 L11×
- Build height (Z)100 mm vs 295 mm3×
- Finest layer height0.1 mm vs 0.05 mm2×
- Number of supported materials1 vs 44×
- Build depth (Y)110 mm vs 220 mm2×
- Build width (X)120 mm vs 220 mm+83%
Specifications
Side by side
| General | ||
| Technology | FDM / FFF (filament) | FDM / FFF (filament) |
| Motion system | — | Bed-slinger (i3-style) |
| Delivered as | — | Partially assembled |
| All-metal frame | — | Yes |
| Build volume | ||
| Build width (X) | 120 mm | 220 mm |
| Build depth (Y) | 110 mm | 220 mm |
| Build height (Z) | 100 mm | 295 mm |
| Build volume | 1.3 L | 14.3 L |
| Speed | ||
| Max print speed | — | 150 mm/s |
| Print quality | ||
| Finest layer height | 0.1 mm | 0.05 mm |
| Thickest layer height | — | 0.3 mm |
| Extruder & hotend | ||
| Max nozzle temperature | — | 260 °C |
| Direct-drive extruder | — | Yes |
| Default nozzle | — | 0.4 mm |
| Nozzle material | — | brass |
| Toolheads | — | 1 |
| Nozzles | — | 1 |
| Filament diameter | — | 1.75 mm |
| Supported materials | PLA | PLA, PP, PVA, TPU |
| Number of supported materials | 1 | 4 |
| Engineering materials (PA, PC, CF) | No | No |
| Print bed | ||
| Heated bed | — | Yes |
| Max bed temperature | — | 80 °C |
| Connectivity & control | ||
| Connectivity | USB, SD card | USB, SD card |
| Wi-Fi | No | — |
| Ethernet | No | — |
| USB | Yes | Yes |
| SD card | Yes | Yes |
| Bluetooth | No | — |
| Screen size | — | 3.5″ |
| Touchscreen | — | Yes |
| Features | ||
| Built-in camera | — | No |
| Filament runout sensor | — | Yes |
| Power-loss recovery | — | Yes |
| Size & power | ||
| Width | 210 mm | 445 mm |
| Depth | 210 mm | 485 mm |
| Height | 290 mm | 550 mm |
| Weight | 3 kg | 11 kg |
| Rated power | — | 300 W |
