- Ender-3 S1 Pro vs mCreate
Creality Ender-3 S1 Pro vs Makeblock mCreate
What Ender-3 S1 Pro does better (1) and where mCreate wins (3) — every spec side by side.
vs
5.0Build volume6.2
Dimensions
Size comparison
Ender-3 S1 PromCreate
| Ender-3 S1 Pro | mCreate | Difference | |
|---|---|---|---|
| Height | 625 mm | 550 mm | +75 mm |
| Width | 490 mm | 445 mm | +45 mm |
| Depth | 455 mm | 485 mm | −30 mm |
| Weight | 8.6 kg | 11 kg | −2.4 kg |
Drawn to the same scale from the official dimensions (front and side).
Why is Ender-3 S1 Pro better than mCreate?
- Weight8.6 kg vs 11 kg+28%
Why is mCreate better than Ender-3 S1 Pro?
- Build volume13.1 L vs 14.3 L+9%
- Number of supported materials1 vs 44×
- Build height (Z)270 mm vs 295 mm+9%
Specifications
Side by side
| General | ||
| Technology | — | FDM / FFF (filament) |
| Motion system | — | Bed-slinger (i3-style) |
| Delivered as | — | Partially assembled |
| All-metal frame | — | Yes |
| Build volume | ||
| Build width (X) | 220 mm | 220 mm |
| Build depth (Y) | 220 mm | 220 mm |
| Build height (Z) | 270 mm | 295 mm |
| Build volume | 13.1 L | 14.3 L |
| Speed | ||
| Max print speed | — | 150 mm/s |
| Print quality | ||
| Finest layer height | — | 0.05 mm |
| Thickest layer height | — | 0.3 mm |
| Extruder & hotend | ||
| Max nozzle temperature | — | 260 °C |
| Direct-drive extruder | — | Yes |
| Default nozzle | — | 0.4 mm |
| Nozzle material | — | brass |
| Toolheads | — | 1 |
| Nozzles | — | 1 |
| Filament diameter | 1.75 mm | 1.75 mm |
| Supported materials | TPU | PLA, PP, PVA, TPU |
| Number of supported materials | 1 | 4 |
| Engineering materials (PA, PC, CF) | No | No |
| Print bed | ||
| Heated bed | — | Yes |
| Max bed temperature | — | 80 °C |
| Connectivity & control | ||
| Connectivity | USB, SD card | USB, SD card |
| Wi-Fi | No | — |
| Ethernet | No | — |
| USB | Yes | Yes |
| SD card | Yes | Yes |
| Bluetooth | No | — |
| Screen size | — | 3.5″ |
| Touchscreen | Yes | Yes |
| Features | ||
| Built-in camera | — | No |
| Filament runout sensor | — | Yes |
| Power-loss recovery | — | Yes |
| Size & power | ||
| Width | 490 mm | 445 mm |
| Depth | 455 mm | 485 mm |
| Height | 625 mm | 550 mm |
| Weight | 8.6 kg | 11 kg |
| Rated power | 350 W | 300 W |
